Superheat Calculator
Calculate superheat for air conditioning systems to ensure optimal performance and prevent compressor damage.
For Licensed & Trained HVAC Technicians Only
This checklist is intended exclusively for use by licensed, certified, and trained HVAC professionals. It is not a DIY guide and should not be used by untrained individuals to perform repairs or diagnostics. The purpose of this checklist is to help qualified technicians maintain a consistent, step-by-step workflow so that no critical step is overlooked or skipped during service.
Superheat Calculator
Read from the low-side gauge on your manifold
Measure at the suction line near the service valve
What is Superheat?
Superheat is the difference between the actual temperature of refrigerant vapor and its saturation temperature at a given pressure. It ensures that only vapor (not liquid) enters the compressor, protecting it from damage.
How to Measure Superheat
- Connect your manifold gauges to the service ports
- Read the suction pressure from the low-side gauge (PSIG)
- Attach a temperature probe to the suction line near the service valve
- Record the suction line temperature
- Use this calculator to determine superheat and system status
Superheat Guidelines
Refrigerant Types
R-410A
Common refrigerant in modern mini-split and residential AC systems. Being phased out due to environmental concerns.
R-32
Newer, more environmentally friendly refrigerant with lower global warming potential. Increasingly common in mini-splits.
R-454B
Next-generation refrigerant designed to replace R-410A with significantly lower environmental impact.
